NH blade Fuse Link and fuse base

Low power loss NH(NT) fuses & fuse bases for industrial protection, conform to Class GL/GG and Class aM, gR, aR. General industrial applications or for the protection of motor circuits.

Version with voltage free metal gripping lugs for insulated fuses.Light yellow ceramic available.

Rated Voltage

400VAC/500VAC/690VAC

Rated Current

10A~100A/125A/160A/200A, 250A/315A/400A/500A/630A/800A

Usage

Low Voltage

Type

NH000,NH00,NH0,NH1,NH2,NH3,NH4

Safety Standard

IEC60269,EN60269

Price range: $1.05 – $20, Stock: More than 1000pcs.

Production Process

Professional production of electrical products, as circuit breakers, mould case circuit breakers, contactors, which supporting copper and iron parts, monthly output of 550,000 sets; Have all kinds of stamping die design self-made ability. Products: conductive system, static contact, iron parts, packaging parts.

Technological process: materials→Molding→screw tap→electroplate→electro welding→riveting→testing→packing

Details about NH blade Fuse Link and fuse base

(Last Updated On: 2020年7月14日)

                                                    Service Condition:

Voltage rating: up to 1140V

Current rating: up to 1250A

Temperature range:-5°C to +40°C

Height above sea level:≤2000m

Humidity: no exceed 50% while the temperature is +40°C

no exceed 90% while month average temperature no exceed 25 °C

Standard: IEC60269, EN60269

Class of pollution: third class

HRC NH blade Fuse Link and fuse base NH000,NH00,NH0,NH1,NH2,NH3,NH4 500V AC 10A~100A, 125A, 160A, 200A, 250A,315A,400A,500A630A



HRC NH blade Fuse Link and fuse base NH000,NH00,NH0,NH1,NH2,NH3,NH4 500V AC 10A~100A, 125A, 160A, 200A, 250A,315A,400A,500A630A



HRC NH blade Fuse Link and fuse base NH000,NH00,NH0,NH1,NH2,NH3,NH4 500V AC 10A~100A, 125A, 160A, 200A, 250A,315A,400A,500A630A





HRC NH blade Fuse Link and fuse base NH000,NH00,NH0,NH1,NH2,NH3,NH4 500V AC 10A~100A, 125A, 160A, 200A, 250A,315A,400A,500A630A



Technical Parameters

Fuse Type Rated voltage Rated cuttent (A)  Rated breaking

capacity (KA)

Rated power
dissipation of
fuse-link (W)
Weight of
base (G)
Weight of  fuse link (G)
Base Fuse-link 500V 690V COSφ
RT16-00 500V
690V
160 2,4,6,8,10,12,16,20,25,32,40,50,63,80,100,125,160 120 50 0.1~0.2 ≤12 200 170
RT16-0 160 2,4,6,8,10,12,16,20,25,32,40,50,63,80,100,125,160 50 ≤25 300 280
RT16-1 250 80,100,125,160,200,200 50 ≤32 700 450
RT16-2 400 125,160,200,250,315,000 50 ≤45 1150 660
RT16-3 630 315,400,500,630 50 ≤60 1280 850
RT16-4 400V 1250 70,080,010,001,250 400V
100kA
≤110 3400 2480



NT(NH) Fuse Base NT3 Fuse BaseNT(NH) Fuse Base NT3 Fuse BaseFAQ:

 1. MOQ:—-1 pc is available. Free sample

2. Payment:—-T/T, L/C, Western Union, Paypal

3. Delivery time:—-The goods need about 30 days to be made after receiving a deposit. For samples, orders can be prepared 5 days after receiving a deposit.

4. Shipment:

—-Large quantity we prefer to deliver by sea, small quantity, and sample orders can be by DHL, UPS, ARAMEX, or another way you prefer.

5. Why choose us?

—-a. We are a professional manufacturer. All parts are made by ourselves, and we will have a random inspection with 5% of each batch in our own professional laboratory which equipt with the dielectric tester, salt spray tester, temperature rise tester, and coating thickness tester.

—-b. 100% QC inspection before shipping.
—-c. OEM is available.
